• #40 Taper, 20,000rpm and #50 Taper, 12,000rpm geared spindle configurations. HSK-A63 spindle available as an option.
• Positioning Accuracy: ±0.000078”/full stroke, Repeatability: ±0.000039”.
• Solid box way construction, linear scales on all axes and twin ballscrew design in the X & Y axes.
• High speed 4th axis rotary table, Integral Motor Driven 43,200deg/min (120rpm) rapids.
• World’s fastest rapid feed rates of 2,362ipm on induction hardened solid box ways
• Standard 2-station APC offers the ability to add pallets and pallet pool systems in the field.
• Beats the competition in work envelope size and stroke!
• The ability to add 630mm tables in the field as an option.
| Table Size: | 19.7” x 19.7” (500 x 500mm) |
| Travel (X, Y, Z): | 34.3” x 31.5” x 36.6” (870 x 800 x 930mm) |
| Spindle Taper: | NST No. 40 |
| Spindle Speed: | 20~20,000rpm – Gear Drive, 4-Step |
| Tool Storage Capacity: | 50 Pcs. (100,150,200 Opt.) |
| Tool Change Time (T-T/C-C): |
1.3 sec. /3.8 sec. |
| Rapid Feed (X,Y,Z) Rapid Feed (B) |
2,362ipm (60m/min) 43,200deg./min. (120rpm) |
| Power Requirement: | 55KVA |
